Frequently Asked Questions About Atomic Force Microscopy

An atomic force microscopy (AFM) is a type of scanning probe microscope (SPM). It uses a very sharp probe that is raster-scanned to produce a true 3D topographical map of the surface of a sample with nanoscale resolution.

_{LEARN MORE:}

Atomic force microscopy is a type of scanning probe microscopy (SPM), but it is not the only type. Atomic force microscopy and scanning tunnelling microscopy (STM) are the two most common types of SPM.

All types of scanning probe microscopes use a physical probe touching the surface of a sample to scan the surface and collect data. However, their measurement mechanisms are very different:

• STM uses an electrical current between the microscope’s scanning tip and the sample surface; samples must be conductive or semi-conductive.
• AFM measures the cantilever deflection (bending) caused by forces between the tip and the sample surface; AFM can be used to measure a much wider range of materials than STM.

_{LEARN MORE:}

Atomic force microscopes are classified as either ‘"tip-scanning," in which the AFM probe is scanned over a stationary sample, or as "sample-scanning," in which the sample is actively scanned under a stationary AFM probe. A tip-scanning configuration provides significant advantages with regards to system versatility and sample size. As the sample is not moved, tip-scanning systems can accommodate much larger, heavier samples or multiple smaller samples, and are more easily modified to correlate/integrate additional techniques.

Bruker’s Large-Sample AFMs are tip-scanning systems. The resulting open-access platform delivers maximum flexibility to accommodate the widest variety of experiments, modes, techniques, and semi-automated measurements without compromising performance.

_{LEARN MORE:}

Contact Mode

Contact mode was the first AFM imaging mode and is the basis for all other AFM techniques in which the probe tip is in constant physical contact with the sample surface.

How does contact mode AFM work?

• As the AFM probe scans along the top of the sample, height variations in the sample surface induce a vertical deflection of the cantilever.
• A feedback loop maintains the vertical deflection at a preset load force and uses the feedback response to generate a topographic image.

Though reasonably easy to operate, contact mode has the inherent drawback that the lateral forces exerted on the sample during scanning can be quite high. These forces can result in sample distortion/damage or the movement/displacement of relatively loosely attached objects.

Tapping Mode

TappingMode AFM was developed to address the high lateral forces associated with contact mode.

How does tapping mode AFM work?

• The AFM cantilever is oscillated close to its resonant frequency while perpendicular to the sample surface. As the tip intermittently “taps” along the surface, height variations cause changes in the amplitude of the oscillation.
• The feedback loop increases/decreases the tip-sample distance to maintain a constant amplitude and uses this movement to produce a topography image.

The development of TappingMode enabled researchers to acquire high-resolution topographical images of samples too fragile to withstand the lateral forces of contact mode.

_{LEARN MORE:}

While the introduction of TappingMode enabled AFM imaging for a much wider range of samples, its one drawback compared to contact mode is that it cannot directly measure forces. Bruker’s PeakForce Tapping, however, solved this issue by performing a force curve at every pixel position on the sample surface.

How it works:

• PeakForce Tapping is a non-resonant imaging mode, where the tip-sample distance is modulated in a sinusoidal motion at amplitudes that are typically less than 100 nm and at typical frequencies of 1-2 kHz.
• When the AFM probe is brought into contact with the sample surface, the tip-sample interaction is controlled by holding the maximum force, or “peak force,” between the tip and the sample constant.

An advantage that PeakForce Tapping has over other force-distance curve-based imaging modes is that it utilizes a continuous feedback loop to adjust the relative tip-sample position. As such, the imaging force control benefits from the results of the previous tip-sample interactions. PeakForce Tapping also uses sinusoidal ramping rather than linear ramping so that as the tip moves closer to the surface, its velocity approaches zero.

Together, these features of PeakForce Tapping enable direct and precise control of the tip-sample interaction force, facilitating imaging at forces down to ~10 pN. This superior force control maintains tip shape and sample integrity, leading to consistently accurate and high-resolution imaging of even the smallest structures, such as atomic defects and DNA double helix.

As a force-distance curve-based mode, perhaps the greatest power of PeakForce Tapping technology comes from its ability to simultaneously enable and enhance other correlative and quantitative mapping techniques, delivering new possibilities in an ever-expanding set of topographical, mechanical, biological, electrical and chemical applications at the nanoscale.

_{LEARN MORE:}

AFM is a highly accurate technique, and additionally has a high resolution and repeatability when following well-defined standard procedures and maintenance. Accuracy is fundamentally tied to resolution, which can be affected by the probe tip, system noise, and the sample itself. Additionally, accuracy for quantitative techniques depends on the accuracy of all other variables in the system. Bruker takes extreme care to enable AFM users to get the most accurate, high-resolution, and highly repeatable measurements possible.

To ensure accuracy in quantitative techniques like PeakForce QNM and nDMA, Bruker offers:

• Pre-calibrated probes with a QR code that can easily be scanned for quick integration into the analysis workflow.
• Accessible maintenance with a variety of service packages available
• Easy scanner calibration


_{LEARN MORE:}

When considering most standard AFM systems, the scan speed used to obtain optimal quality images strongly depends on several variables, including the sample, probe, imaging mode, scan size, tip-sample interaction forces, and the number of lines collected per image.

How long does AFM imaging take?

For most AFM systems, image acquisition time is on the order of several minutes. While any AFM system can simply scan faster, there is an inherent trade-off between imaging speed and tip-sample force. As such, imaging at higher scan speeds will typically result in lower quality images.

Dedicated high-speed AFM systems, such as Bruker’s Dimension FastScan, are specifically designed to minimize this trade-off such that high-resolution images can be acquired in seconds or several frames per second. By optimizing critical components involved in the system feedback loop, including the XYZ-scanners, laser optics, system electronics, and by using small cantilevers, a substantial improvement in system bandwidth is achieved that allows optimal force control to be maintained at significantly faster imaging speeds.

High-speed AFM imaging greatly improves time to data and overall productivity while enabling direct observation of dynamic processes. Applications that would most benefit from high-speed imaging can be broadly categorized into 3 main areas:

• Survey: the efficient exploration of an unknown, heterogeneous sample, to understand the different morphologies that best represent the surface, and to capture a representative set of images at high resolution.

• Screening: the quantitative characterization of a surface property (roughness, number of phases, particle size and shape, stiffness, etc.) on a large number of samples of the same class. In this case, the AFM images are only an intermediary; the end product is a comparison graph that quantitatively represents the measured property for each of the samples.

• Dynamics: the observation of sample changes over time, at sufficient speed to resolve the observed process (crystallization, dissolution, self-assembly, aging phenomena, etc.).

_{LEARN MORE:}

AFM is generally non-destructive, though some modes may drag the tip along the sample surface, affecting soft or fragile samples. Other AFM modes are conducted with a goal of indenting or scratching the sample. With any AFM mode, there is no damage to the bulk of larger samples. With tapping and PeakForce Tapping modes, there is little to no damage to the sample surface. A comparison to other characterization methods can be found in "What makes atomic force microscopy an ideal technique for studying samples at the nanoscale."

_{LEARN MORE:}

AFM images are always collected as 3 dimensional datasets but can be presented as either 2D contour maps or as 3D plots. These representations often have color scales where darker colors are shorter features and lighter colors are taller features.

Refer to the above table of nanoscale characterization methods for materials to see a comparison to other common techniques.

_{LEARN MORE:}

AFM does not require vacuum, unlike traditional scanning tunneling microscopy (STM). A comparison to other characterization methods can be found in "What makes atomic force microscopy an ideal technique for studying samples at the nanoscale."

_{LEARN MORE:}

Bruker AFMs are advantageous because they can be used to conduct studies in a wide variety of different sample environments. There are available capabilities to enable measurements in liquid, temperature control, and humidity control. AFM is a highly adaptable technique, and if your sample requires additional considerations, please do not hesitate to contact our experts.

_{LEARN MORE:}

Bruker offers a versatile range of AFM instruments that can be equipped with many scanning modes, offering solutions for every application.

Additionally, the Dimension XR family of AFMs offers turnkey system solutions that deliver unique, first-and-only modes and capabilities for the utmost performance in advanced materials research. These optimized AFM packages deliver the highest performance to address nanomechanical, nanoelectrical, and nanoelectrochemical applications.

_{LEARN MORE:}

Bruker offers a versatile range of AFM instruments capable of imaging a broad range of sample sizes. We are happy to recommend specific instrumentation, operational modes, and configurations to enable highest quality measurements on large samples in your specific application.

The Dimension Icon is the world’s most-proven, highest-performance, and most-versatile large-sample AFM platform. With wide-open tip and sample access, an unrivalled suite of operating modes and accessories, and numerous ease-of-use features, the Dimension Icon delivers the most complete AFM solution for the widest range of applications.

The Dimension Nexus provides the highest levels of AFM performance, functionality, and accessibility in its class. Designed to deliver expert-level results easily and consistently, the Dimension Nexus provides large-sample AFM capabilities and techniques to researchers at price points well below expectations for such performance.

_{LEARN MORE:}

Bruker offers a versatile range of AFM instruments capable of imaging a broad range of sample sizes. We are happy to recommend specific instrumentation, operational modes, and configurations to enable highest quality measurements on small samples in your specific application.

As the benchmark advanced-research AFM, the MultiMode’s long history of success is based on its combination of market-leading highest-resolution, superior performance, unparalleled versatility, and proven record of productivity and reliability. With the latest features and accessories, the MultiMode 8-HR takes this legendary AFM platform to even higher levels of performance, speed, and ease of use.

The compact Innova AFM delivers routine high-resolution imaging and application flexibility for a wide range of materials science research. With its highly customizable feature set, Innova offers the utmost value in a research AFM at a moderate cost.

_{LEARN MORE:}

Bruker Materials Research AFMs offer industry-leading performance and accuracy in semiconductor applications. We are happy to recommend specific instrumentation, operational modes, and configurations to enable highest quality measurements on semiconductor materials and devices for your specific application.

The Dimension FastScan Pro delivers the highest metrology-level speed and performance of any industrial AFM. The system enables automated or semi-automated measurements for full coverage of 200 mm wafers, or multiple samples within a 200 mm area, with optional chucks for 300 mm wafers. Ensuring the utmost in ease-of-use and reliability, the Dimension Pro delivers the lowest cost per measurement for quality control, quality assurance, and failure analysis.

The IconIR300 large-sample nanoscale infrared (IR) spectroscopy system provides high-speed, high-accuracy nanoscale characterization for semiconductor applications. Through its combination of proprietary photothermal IR spectroscopy for chemical ID and nanoscale AFM property mapping capabilities, the IconIR300 enables automated wafer inspection and defect identification on the widest range of wafer (up to 300 mm) and photomask samples.

_{LEARN MORE:}

Bruker Materials Research AFMs achieve high speeds without compromising measurement quality. We are happy to recommend specific instrumentation, operational modes, and configurations to enable highest quality high-speed measurements for your specific application.

The Dimension FastScan is the first-and-only high-speed tip-scanning system that achieves frames per second (fps) scan rates without compromising resolution or system performance – independent of sample size. Whether collecting survey scans at >125 Hz to find specific regions of interest or capturing the dynamic behavior of a sample at rates of 1 fps in air or fluid, FastScan redefines the AFM experience.

_{LEARN MORE:}

The Dimension IconIR system combines nanoscale infrared (IR) spectroscopy and AFM on a single platform to deliver the most advanced spectroscopy, imaging, and property mapping capabilities available for materials research. The IconIR enables correlative microscopy and chemical imaging with sub-10 nm resolution and monolayer sensitivity on a large-sample platform to provide the ultimate sample flexibility for the broadest range of applications.

_{LEARN MORE:}

All of Bruker’s Materials Research AFMs are capable of operating in fluid and offer environmental control options for studies on biological samples. This provides the flexibility often required for AFM systems used in multi-user facilities or multi-focused research groups.

Investigators who are mainly focused on biological research and/or AFM integration with light microscopy techniques should refer to Bruker’s BioAFM systems to best address their research requirements.
