New Possibilities: Full Range EDS Analysis with SEM XRF

On-Demand Session - 60 minutes

Unlock the Full Potential of your EDS Detector with SEM XRF

The addition of a micro-XRF excitation source to a Scanning Electron Microscope (SEM) equipped with an EDS detector opens up a world of new analytical possibilities.

In this webinar we will present SEM-based micro-XRF and how it can expand your systems workflow with new analytical capabilities.

The use of a micro-XRF source allows users to overcome the limits of conventional EDS - allowing for trace element detection, layer analysis and the detection of high-energy X-ray lines. In addition, all of these benefits can also be carried out on samples with minimal preparation and that may be irregular in shape or larger than normally considered. Such possibilities turn your SEM into a Full Range EDS system.

Our micro-XRF source, XTrace 2, is equipped with a powerful 50 W micro-focus X-ray Rh tube (35 or 10 um optics), and features such as auto source retraction mode, an Aperture Management System (AMS), and Flexispot Mode, meaning it is now possible to analyze large samples at a micrometer scale.

Join us to to discover Full Range EDS and to explore how this technology can be used across a range of applications.



Who Should Attend?

  • Scientists and researchers from all analytical fields interested in elemental analysis and electron microscopy.
  • SEM users who want to learn about large area trace element mapping using micro x-ray fluorescence.
  • SEM users who would like to analyze elements in layered samples.
  • Micro-XRF on SEM users who would like to increase their analytical capabilities.
Element intensity map of Ni, Cu, and Zn from a Euro coin clearly indicating the different compositions.
Analysis of grains from a diamond exploration project. The grains are eclogitic garnet and clinopyroxene and are measured as is with no sample preparation.
Large area map of a PCB electronic component highlighting the distribution of key elements over a topographically challenging surface.
