Elexsys

ELEXSYS-II E500 CW-EPR

Ultimate sensitivity in CW-EPR - SuperX: an ELEXSYS-II feature for the ultimate sensitivity in CW-EPR

The X-Band ELEXSYS-II instruments are equipped with the SuperX feature and the new signal processing unit (SPU). SuperX comprises a selected high-power, ultra-low-noise Dual Gunn source, and the super-high-Q cavity.

The combination of these devices has resulted in an order of magnitude increase in sensitivity for CW-EPR in X-band. For the traditional sensitivity measurement, we specify a weak-pitch signal-to-noise of 3000:1 for the E500 CW-EPR spectrometer.

The SPU is a highly integrated device taking care of all acquisition modes in modern CW-EPR. With a total of 8 signal input channels and various trigger modes, even experiments that are not part of the standard EPR repertoire can be mastered.

One demonstration of the improvement in sensitivity with the SuperX system is shown here for spectra obtained from a Cu²⁺ Histidine in a standard cavity (left) and with the SuperX system (right). What appeared as a weak and uninformative spectrum with the standard cavity is a clear and well-resolved spectrum with the new SuperX system.

Applications

epr-chemistry-banner

EPR in Chemistry

Metal centers, organic and inorganic radicals involved in chemical processes can be studied by EPR in various branches of chemistry: coordination chemistry, metalloorganic compounds, electrochemistry, redox processes, kinetics involving radical intermediates, photochemistry and catalysis.
Leggi di più
EPR in material science

EPR in Material Science and Physics

Within the areas of physics and material science there are many topics of interest. EPR can be employed to investigate polymer synthesis and degradation, paint properties, testing the purity and stability of photovoltaics, semiconductors, batteries as well as carbon nanotubes. Furthermore, information can be gained about the coordination environment of transition metals, rare-earth and actinide ions.
Leggi di più
EPR in Life Science

EPR in Life Science

EPR is a powerful tool in the field of life sciences. EPR provides insight into the structure, function and reaction mechanisms of enzymes, membrane proteins, RNA/DNA, and for characterization/screening of DNP agents. Using spin-labeled biomacromolecules enables you to study their structure and dynamics. EPR detects and quantifies reactive oxygen and nitrogen species (ROS/RNS) including nitric oxide.
Leggi di più
Distribution

EPR in Pharma

EPR spectroscopy is a powerful tool in various areas of pharmaceutical analysis: detection and evaluation of degradation, stability and shelf-life, reaction monitoring, sterilization processes and profiling of paramagnetic impurities.
Leggi di più
EPR in Industry

EPR in Industry

In industrial settings, a wide variety of properties of products are analyzed by EPR: oxidative stability and antioxidant capacity of foods and beverages, determination of radiation dosage, post-irradiation effects on products, polymer analysis to determine failure rates, and diamond quality.
Leggi di più

Features

Signal Processing Unit (SPU) Features

  • Digital lock-in with up to 5 simultaneously detected harmonics
  • Simultaneous detection of 0 and 90 degree modulation phases
  • Modulation frequencies up to 1 MHz
  • Dual input channels for simultaneous absorption and dispersion measurement
  • 27 bit amplitude dynamic range
  • Rapid scan ramp generator and detection system for modulated and direct detection
  • Transient recorder with 14 bit single shot amplitude resolution and 8 ns time resolution
  • Predefined and user input channels
  • Input channels with AC and DC coupling
  • Internal and External triggers
  • 256 000 points on field and time axis
  • 65 536 points on transient time axis

E 500 Highlights & Standard Features

  • SuperX microwave units for world record sensitivity
  • Ultra high resolution field controller
  • Digital rapid field scan module
  • Stationary and time resolved experiments
  • Multi-purpose signal processing unit (SPU)
  • Reference free spin counting
  • Xepr software package

Computer System

A LINUX based front-end workstation running the Xepr software package a software acquisition server handling all real time events.

Specifications

X-band sensitivity 1.0 x 109
Weak pitch signal-to-noise ratio 3000 : 1
Modulation frequency 100 Hz to 100 kHz in 1 kHz steps
Modulation amplitude up to 20 G
Field stability 10 mG / hour
Sweep resolution 256 000
Amplitude resolution 32 bit
Detection digital filtering, no time constant needed
  AC and DC input
  dual input channels
Simultaneous detection multiharmonic, up to 5th order
  0° / 90° modulation phase
Transient recorder mode 8 ns time resolution
