RAID-XP
Features
A new dimension in detection
Hardened to military standards, reliable and robust; RAID-XP is able to detect, identify and continuously monitor Chemical Warfare Agents (CWA) & Toxic Industrial Chemicals (TIC) using a high end Ion Mobility Spectrometer.
Simultaneously semiconductor sensors and two photo diodes are used for the detection and quantification of gamma radiation, dose rate and accumulated dose. Data monitoring and interrogation is achieved through a clear, unambiguous dual display and easy to operate integral software menus. RS232 and GPS interface are enabled.
The RAID-XP is a robust and flexible instrument built with trusted Bruker technology that is capable of operating standalone or mounted in vehicles.
Applications
To mitigate the combined threats from both chemical warfare agents (CWA) and/or radiation, Bruker has developed the innovative RAID-XP Series.
The RAID-XP combines chemical and radiological threat detection into a single system, and provide the enhancement of also detecting toxic industrial chemicals (TIC).
Typical applications include
- Military use, especially perimeter monitoring, counter-terrorism and civil defence applications
- Installation to mobile platforms such as ships, reconnaissance vehicles, mobile laboratories, and civilian and police emergency response vehicles
Specifications
Combined sensors for Radiological detection and CWA's
The RAID-XP Series provides dual chemical and nuclear detection capabilities in a lightweight, man-portable platform.
The detection systems combine the principle of ion mobility spectrometry, the de-facto standard for CWA/TIC detection, and PiN diodes are used to detect gamma radiation, displaying dose rate and accumulated dose. Individual displays indicate the respective threats from CWA/TIC and gamma radiation. Two versions are offered. The RAID-XP uses a standard 63Ni source, whereas the new RAID-XPNR uses a High Energy Photoionisation (HEPI) source. Both source versions can be selected.
RAID-XP Features
- Designed for use in harsh environments
- Continuous and automatic detection
- Lightweight and Portable
- Dual display
- Simple operation
Literature Room
Learn more about our products and solutions by downloading related literature.
Service & Support
Bruker Detection services are performed by factory trained engineers. DIN EN ISO 9001:2000 requirements are fulfilled.
Available services include:
- Planned maintenance, according to your requirement
- Factory repairs for your instrument with quick turnaround times
- Customer on-site repair and maintenance service
